空載 | 最高效率點 | 堵轉 | ||||||||||
電機型號 | 工作電壓 | 轉速r/min | 電流A | 轉速r/min | 電流A | 力矩mNm | 功率W | 效率% | 電流A | 力矩mNm | ||
QRS-790SH | 6VDC | 3280 | 0.61 | 2880 | 4.4 | 64.6 | 19.48 | 73.9 | 31.7 | 530.35 | ||
QRS-790SH | 12VDC | 8500 | 0.9 | 7476 | 6.57 | 52.92 | 41.43 | 52.5 | 48 | 439.3 | ||
QRS-795SH | 12VDC | 15000 | 1.98 | 13211 | 14.6 | 95.66 | 132.3 | 75.4 | 108 | 802 | ||
QRS-795SH | 24VDC | 5500 | 0.25 | 4853 | 1.87 | 65.4 | 33.2 | 73.9 | 14 | 554.7 |
