空載 | 最高效率點 | 堵轉 | ||||||||||
電機型號 | 工作電壓 | 轉速r/min | 電流A | 轉速r/min | 電流A | 力矩mNm | 功率W | 效率% | 電流A | 力矩mNm | ||
QRS-770SH | 12VDC | 15200 | 2 | 13.5 | 15.9 | 103.6 | 146.5 | 76.8 | 126 | 927.9 | ||
QRS-770SH | 12VDC | 18600 | 2.5 | 15779 | 13.96 | 707 | 114.46 | 68.33 | 78 | 457 | ||
QRS-775SH | 12VDC | 7050 | 0.52 | 6244 | 4.03 | 56.03 | 36.64 | 75.8 | 31.2 | 490 | ||
QRS-775SH | 18VDC | 18300 | 2.11 | 16103 | 15.46 | 123.1 | 207.7 | 74.6 | 113.3 | 1025.9 |
