空載 | 最高效率點 | 堵轉(zhuǎn) | ||||||||||
電機型號 | 工作電壓 | 轉(zhuǎn)速r/min | 電流A | 轉(zhuǎn)速r/min | 電流A | 力矩mNm | 功率W | 效率% | 電流A | 力矩mNm | ||
QRS-750SH | 12VDC | 9000 | 1.1 | 7579 | 5.93 | 53.69 | 42.69 | 60 | 32 | 343.2 | ||
QRS-750SH | 12VDC | 1700 | 0.09 | 1408 | 0.44 | 22.39 | 3.3 | 63.2 | 2.1 | 130.42 | ||
QRS-755SH | 12VDC | 18500 | 1.8 | 15729 | 10.22 | 48.18 | 79.36 | 64.7 | 58 | 321.7 | ||
QRS-755SH | 12VDC | 17480 | 1.78 | 15343 | 13.43 | 75.3 | 121.77 | 75.6 | 101.3 | 643.7 |
