空載 | 最高效率點 | 堵轉 | ||||||||||
電機型號 | 工作電壓 | 轉速r/min | 電流A | 轉速r/min | 電流A | 力矩mNm | 功率W | 效率% | 電流A | 力矩mNm | ||
QRS-5512PA | 220VAC | 14000 | 0.06 | 11580 | 0.42 | 50.5 | 61.19 | 63.3 | 2 | 292 | ||
QRS-5512PA | 230VAC | 18600 | 0.19 | 14894 | 0.75 | 67.3 | 104.68 | 60.66 | 3 | 336.9 |
